Dichotomous Key

AI 101

What is a Dichotmous Key?

…an identification key where the sequence and structure of identification steps is fixed by the author of the key. At each point in the decision process, multiple alternatives are offered, each leading to a result or a further choice.

Why do we care?

Single access keys are closely related to decision trees and binary search trees. However, to improve the usability and reliability of keys, many single-access keys incorporate reticulation, changing the tree structure into a directed acyclic graph. Single-access keys have been in use for several hundred years.

  • They:
    • Predate computers, yet
    • Use state-of-the-art techniques in computing.
  • We study them as a way to understand AI

Motivating Example

  • I learned about dichtomous keys in biology class, and only realized the connection years latter.
  • In the spirit of good ole biology, a real science, we will study the example of “botanical classification of oaks.”
    • Please under absolutely no circumstances ask me anything about biology.
    • I do not know and will embarrass myself and may confuse or even horrify you.
    • Biology is cool though!

The Key

  • Basically, a key is a branching series of yes/no questions.
    • The dichotomous key gets its name from having two (“di”) possibilities for any case
    • “yes” and “no” or “true” and “false” or etc. etc.
  • To classify an oak, there are a series of questions that a non-expert can answer by inspecting the tree, such as being looking at the whole tree or looking at its leaves.
  • After answer a question, there is either a reference to a new question, usually by number, or a note that you have determined what the type of tree is.

Example

1. Leaves usually without teeth or lobes: 2
1. Leaves usually with teeth or lobes: 5

    2. Leaves evergreen: 3
    2. Leaves not evergreen: 4

3. Mature plant a large tree — Southern live oak Quercus virginiana
3. Mature plant a small shrub — Dwarf live oak Quercus minima

    4. Leaf narrow, about 4-6 times as long as broad — Willow oak Quercus phellos
    4. Leaf broad, about 2-3 times as long as broad — Shingle oak Quercus imbricaria

5. Lobes or teeth bristle-tipped: 6
5. Lobes or teeth rounded or blunt-pointed, no bristles: 7

    6. Leaves mostly with 3 lobes — Blackjack oak Quercus marilandica
    6. Leaves mostly with 7-9 lobes — Northern red oak Quercus rubra

7. Leaves with 5-9 deep lobes — White oak Quercus alba
7. Leaves with 21-27 shallow lobes — Swamp chestnut oak Quercus prinus

Visually

  • You may have to zoom in…

OakKey Start Leaves are smooth with no teeth or lobes? Evergreen Laves evergreen? Start->Evergreen True Bristles Lobes/teeth bristle-tipped? Start->Bristles False GrowthHabit Large Tree (not shrub)? Evergreen->GrowthHabit True LeafShape Leaves more than 3x long as wide Evergreen->LeafShape False LiveOak Southern live oak GrowthHabit->LiveOak True DwarfOak Dwarf live oak GrowthHabit->DwarfOak False WillowOak Willow oak LeafShape->WillowOak True ShingleOak Shingle oak LeafShape->ShingleOak False LobeCount6 3 or fewer lobes? Bristles->LobeCount6 True LobeCount7 9 or fewer lobes? Bristles->LobeCount7 False BlackjackOak Blackjack oak LobeCount6->BlackjackOak True RedOak Northern red oak LobeCount6->RedOak False WhiteOak White oak LobeCount7->WhiteOak True SwampOak Swamp chestnut oak LobeCount7->SwampOak False

Some oaks

  • One problem with using pictures of oaks on the internet is that they usually named something like “I am this type of oak”.png (Portable Network Graphic - the type of image it is) and then when you ask Gemini what type of oak it is, Gemini just reads the name.
  • Not to worry, I downloaded a bunch of pictures of oaks and changed their names.
  • I have given them a temporary name and used “spoiler tags” to hide the actual name.
  • For each tree, I provide an image of the tree and an image of leaves.
    • All are sourced from Wikipedia and appropriately licensed, with the links to the host page in the key.

Key

Click “Details” to expand

Nickname Common Name Scientific Name
A Blackjack oak Quercus marilandica
B Dwarf live oak Quercus minima
C Northern red oak Quercus rubra

Oak A

Oak B

Oak C

URLs

  • I have the best luck with prompting Gemini when I provide images as a URL.
  • Here are the URLs for the leaf and tree of Oak A, the others are similar.

Sorting Oaks

  • Pick one of the three oaks, work through the key, then check your answer!

Take notes

  • Create a “Lab03” Colab notebook (NOT a Google Document) in your AI Folder.
  • Create a text cell in this Colab notebook.
  • Record 140-280 characters worth of thoughts on working through the key - more if you have more thoughts.

Computer Vision

Computer vision tasks include methods for acquiring, processing, analyzing, and understanding digital images, and extraction of high-dimensional data from the real world in order to produce numerical or symbolic information, e.g. in the form of decisions.

  • Prof. Rachel Brown in the CS department is a computer vision researcher and helped develop this course!
  • We will use the dichotomous key and Google Gemini to to classify oaks, from their images, as one of the 8 species in our key.

Your Task

  • To implement our dichotomous key we will:
    • Share images with Gemini
    • Ask Gemini a question about the images.
    • Based on the answer, either:
      • Ask a new question, or
      • Give a result, the classification of the tree.

Experimental Design

BEFORE classifying Oaks

  • Write out all of your prompts that you will use.
    • I wrote one each in a code cell, and used text cells to describe what each did.
  • Determine how you will read responses.
    • For example, what will you do if you get an answer other than “yes” or “no”?
    • Can you you address this with different prompts?
  • Set up all your code cells, possibly including cells that with URLs of the three trees.

WHILE classifying Oaks

  • Take clear notes showing how you determine which code blocks to execute in which order.
    • Ensure you are not doing the thinking for the code blocks!

AFTER classifying Oaks

  • While you may iterate, only do so after completely classifying all oaks.
    • You may wish to change prompts, for example, if errors are uncovered.
    • You may have erroneous code blocks.
    • You may mislabel some blocks.
  • You do not need to iterate, but are welcome to do so to improve accuracy!
    • In particular, I benefitted from changing phrasing around some querries to specify two options, and request a one word answer.

Conclusion

Once you have conducted all tests, in your “Lab02” Colab notebook answer the following questions at “social media post” length (150-300 characters). Answer each question at the end of the document, each in its own code cell.

Note

I am specifying a precise way I expect to receive see these questions. Think about why I am doing that and why it may be helpful to following these instructions!

  1. If Gemini correctly classifies the oaks, is this a sign of intelligence?
  2. Is classification of oaks a task that requires intelligence?
  3. Are there examples of classification that require “weak” vs. “strong” AI? You may wish to review slides from the first day of class!
  4. Is this task or the Turing Test a more robust measure of intelligence?
  5. Is your classifier more or less intelligent than a cat?
  6. Is your classifier more or less intelligent than an ecosystem?
  7. Is your classifier more or less intelligent than an assistant professor of computer science? I will note I do not know how to tell oaks apart.
